140CRP93200 Schneider Relay Module
140CRP93200 is a RIO (Remote I/O) head tail adapter module launched
by Schneider Electric, belonging to the Modicon Quantum automation
platform. It adopts a modular design, supports dual cable redundant
connections, and has I/O processing capabilities of 64 inputs/64
outputs. It is suitable for Quantum 200/500/800 series controllers
and achieves high-speed data transmission (1544 Mbit/s) through
coaxial cables (75 ohms) with a dynamic range of 35 dB. It is
equipped with a 2-hole F-connector and redundant cable interface to
enhance system reliability; Its dual power redundant input (DC
9-36V, typical 24V) supports reverse protection, with a power
consumption of less than 4W, and has DC1500V voltage isolation
function. The industrial terminal interface design meets the
requirements of harsh environments; The module adopts a corrugated
aluminum reinforced casing with a protection level of IP30,
supports 35mm DIN rail installation, with dimensions of 132mm ×
105mm × 52mm, a net weight of 800g, a working temperature range of
-10 ℃ to 70 ℃ (optional -40~+85 ℃ wide temperature), a relative
humidity of ≤ 90% (no condensation), and a storage temperature of
-40~80 ℃; Through international certifications such as EN55022 and
EN61000-4-2, it supports fiber optic link failure and power failure
alarm output (contact capacity DC48V/1A), and is widely used in
fields such as CNC machinery, metallurgy, oil and gas, providing
stable and efficient remote I/O expansion solutions for industrial
automation systems.
Technical specifcations for 140CRP93200
Product series and types Modicon Quantum automation platform, RIO
head tail adapter module
64 input/output points (I/O words/drop: 64I/64O)
Cable type: 75 ohm coaxial cable
Transmission rate 1544 Mbit/s
Dynamic range 35 dB
Isolation voltage 500 V DC (coaxial center and ground)
Electrical connection 2-hole F-connector, bent, with redundant
cables
Power consumption 3W (2 channels)
Require bus current of 750 mA (2 channels)
Power input dual power redundant input, DC 9-36V (typical 24V),
power consumption less than 4W, with DC1500V voltage isolation and
reverse protection function
Relay alarm output for fiber link failure and power failure alarm
output, contact capacity: DC48V/1A
Dimensions: 132mm × 105mm × 52mm
The protection level of the shell is IP30, and the corrugated
aluminum reinforced shell is used
Installation method: 35mm DIN rail installation
Net weight 800g
Working temperature range -10 ℃ to 70 ℃ (optional -40 ℃ to+85 ℃
wide temperature range)
Relative humidity ≤ 90% (no condensation)
Storage temperature -40 ℃ to 80 ℃
Product certification FM (Class 1, Class 2), UL 508,CSA C22.2 No
142,CUL, Anti static discharge 4 kV (compliant with IEC 801-2),
anti electromagnetic domain 10 V/m 80... 1000 MHz (compliant with
IEC 801-3)
